.085 in. (2.16mm)
Density
Miniature Ribbon
IDC
Metal Shell
■
■
■
■
■
■
■
■
■
■
Patented contact terminates Discrete Wire (loose or jacketed cable) without stripping or
soldering. Solid and stranded wire versions available.
Metal shell provides grounding and shielding capability.
Available in plug and socket styles in 14, 24, 36, and 50 position sizes.
Designed for panel mount, 180° (Top-Entry), or 90° (Standard) / 270° (Reverse) End-Entry
cable applications.
Available as overmold kit in 36 and 50 position sizes.
All Plugs lock with InstaLatch passive latch feature for automatic latching.
Sockets available with InstaLatches where indicated.
I ndustry-standard bail latch feature available for locking/unlocking without tools in applications
such as SCSI-1 and Centronics.
Full range of application tooling available for termination, unlatching, etc. See page 6-54
for details.
UL Recognized - Files E170218 (UL1977), E130965 (UL1863).
CSA Approved - File LR31996-7 .
Insulator: Blue UL94V-0 rated glass-filled polyester
Contact: Copper alloy
Contact Plating: Select gold over 50μin. select nickel standard;
30μin. select gold over 50μin. select nickel available
where indicated
Shell: Steel
Shell Plating: Zinc with clear chromate coating standard
Tin available where indicated
Operating Temperature: -40 ° C to +105 ° C
Shock: 50G Peak, per EIA Std. RS364, TP27, Condition A
Vibration: 3 cycles @ 10-55Hz in each of 3 axes per EIA Std. 364, TP28,
Condition A
Moisture Resistance: Per EIA Std. RS364, TP31, Condition B, with Step
7B excluded
Voltage Rating:
Withstanding Voltage:
Contact Rating:
Contact Resistance:
500 VAC @ sea level; 125 VAC @ 70,000 ft.
1200 VAC RMS @ sea level, per EIA Std.
RS364, TP20
5 Amps (4 Amps per CSA)
6 milliohms maximum, per EIA Std. RS364, TP6
Contact Resistance Change During Life Conditioning:
Resistance Change
Wire Size (milliohms, max.)
24 AWG Solid 0.5
26 AWG Solid 0.5
26 AWG Stranded 2.0
28 AWG Stranded 5.0
Insulation Resistance:
5000 Megohms minimum initial;
1000 Megohms minimum after moisture
Call Toll Free: 1 (800) 323-9612
6-14
